NVIDIA InfiniBand Compatible 400G OSFP DR4 Flat Top PAM4 1310nm 500m DOM MTP/MPO-12/APC SMF Optical Transceiver
The 400G OSFP DR4 Flat Top transceiver module is designed for use in 400 Gigabit Ethernet links over 500m single mode fiber. The module has 4 independent electrical input/output channels operating up to 106.25Gbps per channel. This transceiver consists of a transmitter/receiver unit, each operating on a set of wavelengths at 1310nm. The transmitter path of the module incorporates a bi-directional PAM4 re-timer ASIC integrated with an EML laser and a 4-channel internal driver. On the receiver path, used 4 photodiodes and a 4-channel TIA array, along with the PAM4 re-timer.
Product Details
| NVIDIA Compatible | MMS4X00-NS400 | Vendor Name | Connlight |
| Form Factor | OSFP | Max Data Rate | 425Gbps |
| Wavelength | 1310nm | Max Distance | 500m |
| Modulation Format | PAM4 | Host Required | FEC |
| Connector | MTP/MPO-12 APC | Voltage Supply | 3.3V |
| Cable Type | SMF | DDM Support | Yes |
| Transmitter Type | 1310nm EML | Receiver Type | PIN |
| TX Power | -2.9~+4.0dBm | Receiver Sensitivity | < -4.4dBm |
| Operation Temperature | 0 to 70°C (32 to 158°F) | Maximum Power | < 12.0W |
| Protocols | OSFP MSA, IEEE 802.3bs | Application | 400G Ethernet, Datacenter Enterprise Networking, Infiniband Interconnects |
Quality Assurance
Excellent quality is the foundation of Connlight’ s survival and development. Our operation team are experts with many years’ experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.
Quality Certification
Comprehensive Testing
Every module is qualified through rigorous procedures and advanced equipment to ensure high-quality and reliable optical devices for you.
